Prroduct Description:

The Qu digital mixer series is designed to be simple for any user to operate. The Qu-16 has 16+1 faders in 3 layers, 16 mono & 3 stereo DSP channels, 4FX units with their own dedicated return, resulting in a total of 30 processing channels. 4 Mono and 3 stereo auxiliary mix busses are available. Every function has a dedicated hardware button to complement the touchscreen. A dSNAKE remote audio port allows Qu-16 to connect to AB & AR AudioRacks as well the ME personal monitor system. 16 Channels of automatic mic mixing, 3 user levels, USB multi-track audio and a customisable fader layout make the Qu-16 a powerful mixer.



KEY FEATURES :


16 Mono + 3 stereo inputs

16 channels of Auto Mic Mixing

dSNAKE for AB & AR remote I/O

External control drivers available

DAW Control

24x22 USB audio interface




FEATURE SUMMARY :




19” Rack Mountable

16 Mono Mic/Line Inputs (TRS + XLR)

Recallable AnaLOGIQTM Preamps

3 Stereo Inputs (TRS)

12 Mix Outputs (XLR)

7 Monitor Mixes (4 mono + 3 stereo)

4 FX Engines

2 dedicated FX Sends / Returns

4 Mute Groups

4 DCA Groups

AES Digital Out

24×22 USB Audio Interface

dSNAKETM Remote Audio Port

17 Motor Faders

800×480 Touchscreen

4 Soft Keys

Trim, polarity, HPF, gate, insert, 4-band PEQ, compressor, delay on all Inputs

Insert, 4-band PEQ, 1/3 octave GEQ, compressor, delay on all Outputs

Automatic Mic Mixer

Channel Ducker on all Inputs

ProFactory Mic Presets

RackFX Library

Built-in Signal Generator

RTA with Peak Band indication

Spectrogram to aid feedback elimination and room acoustics

Qu-Drive Direct Multitrack Recording / Playback on USB drives

DAW MIDI Control

Qu-Pad iPad App

Qu-You iPhone / Android personal monitoring app

Qu-Control customisable iOS app for simple wireless control

Compatible with ME Personal Mixing System

High contrast metallic finish controls, matching premium GLD Chrome series
